Aruba Instant On 1830 8G 10/100/1000 Switch





Aruba Instant On 1830 8G Switch
(JL810A)


Aruba Instant On 1830 8G 4p Class4 PoE 65W Switch (JL811A)


Aruba Instant On 1830 24G 2SFP Switch
(JL812A)


Aruba Instant On 1830 24G 12p Class4 PoE 2SFP 195W Switch
(JL813A)


Aruba Instant On 1830 48G 4SFP Switch
(JL814A)


Aruba Instant On 1830 48G 24p Class4 PoE 4SFP 370W Switch
(JL815A)




I/O ports and slots





8 RJ-45 autosensing 10/100/1000 ports
IEEE 802.3af Class 3 PD (port 1) (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only


8 RJ-45 autosensing 10/100/1000 ports
IEEE 802.3at Class 4 PoE (ports 1-4) (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only


24 RJ-45 autosensing 10/100/1000 ports
(IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
2 SFP 1GbE ports


24 RJ-45 autosensing 10/100/1000 ports
IEEE 802.3at Class 4 PoE (ports 1-12) (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
2 SFP 1GbE ports


48 RJ-45 autosensing 10/100/1000 ports
(IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
4 SFP 1GbE ports


48 RJ-45 autosensing 10/100/1000 ports
IEEE 802.3at Class 4 PoE (ports 1-24) (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
4 SFP 1GbE ports




Physical Characteristics




Dimensions


157.0(d) x 173.0(w) x 39.1(h) mm


195.1(d) x 245.1(w) x 43.9(h) mm


215.9(d) x 443.0(w) x 43.9(h) mm


253.0(d) x 443.0(w) x 43.9(h) mm


253.0(d) x 443.0(w) x 43.9(h) mm


351.0(d) x 443.0(w) x 43.9(h) mm




Weight


1.70 lb (0.77 kg)


3.40 lb (1.54 kg)


5.50 lb (2.49 kg)


7.65 lb (3.47 kg)


7.80 lb (3.54 kg)


10.90 lb (4.94 kg)




Processor and Memory





ARM Cortex-A9 @ 800MHz, 512 MB SDRAM, 256 MB flash; packet buffer: 1.5MB


ARM Cortex-A9 @ 800MHz,
512 MB SDRAM, 256 MB flash; packet buffer: 1.5MB


ARM Cortex-A9 @ 800MHz, 512 MB SDRAM, 256 MB flash; packet buffer: 1.5MB


ARM Cortex-A9 @ 800MHz, 512 MB SDRAM, 256 MB flash; packet buffer: 1.5MB


RM Cortex-A9 @ 800MHz, 512 MB SDRAM, 256 MB flash; packet buffer: 1.5MB


ARM Cortex-A9 @ 800MHz, 512 MB SDRAM, 256 MB flash; packet buffer: 1.5MB






















Aruba Instant On 1830 8G Switch
(JL810A)


Aruba Instant On 1830 8G 4p Class4 PoE 65W Switch (JL811A)


Aruba Instant On 1830 24G 2SFP Switch
(JL812A)


Aruba Instant On 1830 24G 12p Class4 PoE 2SFP 195W Switch
(JL813A)


Aruba Instant On 1830 48G 4SFP Switch
(JL814A)


Aruba Instant On 1830 48G 24p Class4 PoE 4SFP 370W Switch
(JL815A)




Performance




100 Mb latency






















1000 Mb latency






















10000 Mb latency


n/a


n/a


n/a


n/a


n/a


n/a




Throughput (Mpps)


11.90 Mpps


11.90 Mpps


38.68 Mpps


38.68 Mpps


77.37 Mpps


77.37 Mpps




Capacity


16 Gbps


16 Gbps


52 Gbps


52 Gbps


104 Gbps


104 Gbps




MAC address table size (# of entries)


8,000 entries


8,000 entries


16,000 entries


16,000 entries


16,000 entries


16,000 entries




Reliability MTBF (years)


188.2


105.9


203.6


96.6


114.4


83.5




Environment




Operating temperature


32°F to 104°F (0°C to 40°C)


32°F to 104°F (0°C to 40°C)


32°F to 104°F (0°C to 40°C)


32°F to 104°F (0°C to 40°C)


32°F to 104°F (0°C to 40°C)


32°F to 104°F (0°C to 40°C)




Operating relative humidity


15% to 95% @ 104°F (40°C)


15% to 95% @ 104°F (40°C)


15% to 95% @ 104°F (40°C)


15% to 95% @ 104°F (40°C)


15% to 95% @ 104°F (40°C)


15% to 95% @ 104°F (40°C)




Nonoperating/ storage temperature


-40°F to 158°F (-40°C to 70°C)


-40°F to 158°F (-40°C to 70°C)


-40°F to 158°F (-40°C to 70°C)


-40°F to 158°F (-40°C to 70°C)


-40°F to 158°F (-40°C to 70°C)


-40°F to 158°F (-40°C to 70°C)




Nonoperating/ storage relative humidity


15% to 95% @ 140°F (60°C)


15% to 95% @ 140°F (60°C)


15% to 95% @ 140°F (60°C)


15% to 95% @ 140°F (60°C)


15% to 95% @ 140°F (60°C)


15% to 95% @ 140°F (60°C)




Altitude


up to 10,000 ft (3 km)


up to 10,000 ft (3 km)


up to 10,000 ft (3 km)


up to 10,000 ft (3 km)


up to 10,000 ft (3 km)


up to 10,000 ft (3 km)




Acoustics 1





Fanless


Fanless


Fanless


LWAd = 3.1 Bel LpAm (Bystander) = 17 dB


LWAd = 3.4 Bel LpAm (Bystander) = 19 dB


LWAd = 4.0 Bel LpAm (Bystander) = 25 dB




Notes: 1 Acoustics measured in 23°C semi-anechoic chamber with a loading of 100% traffic and (for JL813A and JL815A) 50% PoE on all ports. Measured in accordance with ISO 7779. Declared in accordance with ECMA-109:2010. Values presented are the Declared A-Weighted Sound Power Level (LWAd) and the mean Bystander A-Weighted Sound Pressure Level (LpAm)




100% traffic


Fanless


Fanless


Fanless


LWAd = 3.1 Bel LpAm (Bystander) = 17 dB


LWAd = 3.4 Bel LpAm (Bystander) = 19 dB


LWAd = 3.5 Bel LpAm (Bystander) = 20 dB




100% traffic / 0% PoE


Fanless


Fanless


Fanless


LWAd = 3.1 Bel LpAm (Bystander) = 17 dB


-


LWAd = 3.5 Bel LpAm (Bystander) = 20 dB




100% traffic / 50% PoE


Fanless


Fanless


Fanless


LWAd = 3.1 Bel LpAm (Bystander) = 17 dB


-


LWAd = 4.0 Bel LpAm (Bystander) = 25 dB




100% traffic / 100% PoE


Fanless


Fanless


Fanless


LWAd = 5.1 Bel LpAm (Bystander) = 35 dB


-


LWAd = 5.7 Bel LpAm (Bystander) = 41 dB





Aruba Instant On 1830 8G Switch
(JL810A)


Aruba Instant On 1830 8G 4p Class4 PoE 65W Switch (JL811A)


Aruba Instant On 1830 24G 2SFP Switch
(JL812A)


Aruba Instant On 1830 24G 12p Class4 PoE 2SFP 195W Switch
(JL813A)


Aruba Instant On 1830 48G 4SFP Switch
(JL814A)


Aruba Instant On 1830 48G 24p Class4 PoE 4SFP 370W Switch
(JL815A)




Electrical Characteristics




Frequency


50Hz/60Hz


50Hz/60Hz


50Hz/60Hz


50Hz/60Hz


50Hz/60Hz


50Hz/60Hz




AC voltage


100-127VAC / 200- 240VAC


100-127VAC / 200- 240VAC


100-127VAC / 200- 240VAC


100-127VAC / 200- 240VAC


100-127VAC / 200- 240VAC


100-127VAC / 200- 240VAC




Current


12V -- 1.0A


1.0A/0.5A


0.4A/0.3A


2.7A/1.4A


0.9A/0.6A


5.2A/2.6A




Maximum power rating


100-127V: 8.09W 200-220V: 8.05W


100-127V: 86.07W 200-220V: 83.67W


100-127V: 19.1W 200-220V: 19W


100-127V: 244.6W 200-220V: 237.2W


100-127V: 40.2W 200-220V: 40W


100-127V: 462.5W 200-220V: 452.5W




Idle power


100-127V: 5.8W 200-220V: 5.9W


100-127V: 8.3W 200-220V: 8.2W


100-127V: 7.6W 200-220V: 7.8W


100-127V: 14.5W 200-2...

---
