Popis produktu

Powered by the Intel® Xeon® E platform
95W CPU and up to 128GB memory support (4 DIMMs)
High scalability with two PCIe Gen4 slots and two PCIe Gen3 slots
Flexible storage design with internal 5.25" to 3.5"/2.5" drive cage (Optional)
Dual Intel® Gigabit Ethernet with teaming support
Supports the latest 10Gb/s USB 3.2 Gen2 onboard for high transfer speed
Complete server management with ASUS Control Center
Easily serviceable design
Design for SMB, Web/Print/File/Mail Server, entry storage applications
Onboard audio for workstation applications









Processor / System Bus



1 x Socket LGA1200

Intel® Xeon® processor E-2300 family(95W)

Intel® Pentium Processors

*Refer to support page for more information




Core Logic


Intel® C256 Chipset



Memory



Total Slots : 4  (2-channel)

Capacity : Maximum up to 128GB UDIMM

Memory Type :

DDR4 3200  ECC UDIMM

Memory Size :

32GB, 16GB, 8GB

* Refer to support page for more information




Expansion Slots



Total:4



2 x PCI-E x4 slot, x8 Gen3 Link

1 x PCI-E x8 slot, x8 Gen4 Link

1 x PCI-E x16 slot, x16 Gen4 Link

(Auto switch to x8 link if slot 4 is occupied )






Storage



SATA Controller :

Intel® C256 Chipset

8 x SATA3 6Gb/s ports






Drive Bays



3 x Internal 3.5“ (or 2 x 2.5” optional cage) drive bays

1 x Internal 2.5" drive bay






2 x M.2 (Up to 22110)

Gen4 x4 Link and Gen3 x2 Link

gray SATA port will disable when M.2 is SATA signal





Auxiliary Storage FDD/CD/DVD



2 x 5.25" media bays

(Options: No ODD/DVD-RW)




Networking


2 x Intel® I210AT + 1 x Mgmt LAN



Graphic


Please find the latest GPU support from https://servers.asus.com/support/gpu



Front I/O Ports



2 x USB 3.2 Gen1

2 x USB 2.0

1 x Headphone port

1 x Microphone port




Rear I/O Ports



2 x USB 3.2 Gen2 ports

2 x USB 3.2 Gen1 ports

1 x VGA port (support by ASMB10)

1 x HDMI port from CPU (useable only with iGPU)

2 x LAN Ports

1 x PS/2 Keyboard/ Mouse Port




Switch/LED



Front:

  1 x Power Switch/LED

  1 x Reset Switch

  1 x HDD Access LED




OS Support


Please find the latest OS support from https://servers.asus.com/support/os



Management Solution


Bundle ASMB10-iKVM for KVM-over-IP
ASUS Control Center Enterprise (Optional)



Regulatory Compliance


BSMI, CE, FCC(Class B)



Dimensions



423mm x 190mm x 435mm

16.65" x 7.48" x 17.1"




Weight



Net Weight : 11.56 KG

Gross Weight : 14.68 KG




Power Supply



300W 80PLUS Single Power Supply, Bronze

Rating: 100-127/220-240Vac, 6/3A, 60-50Hz, Class I

550W/750W 80PLUS Single Power Supply, Gold

Rating: 100-240Vac,50-60 Hz,9-4.5A




Environment



Operation temperature: 10? ~ 35?

Non operation temperature: -40? ~ 70?

Non operation humidity: 20% ~ 90% ( Non condensing)




Optional Items



Smart Card Reader

Anti-Virus CD pack

Keyboard and mouse

DVD-RW
Print port cable
Com port cable

---
