be quiet! SHADOW BASE 800 FX, ARGB fan, black

Features:


Impressive lighting, outstanding airflow
The Shadow Base 800 FX white is an airflow-optimized case with ARGB lighting and space for bulky components such as large graphics cards and E-ATX motherboards.
ARGB lighting with ARGB control for maximum design options
Various colors and modes for a custom look
4 Light Wings White 140mm PWM fans provide high airflow with quiet operation
Outstanding high airflow thanks to open mesh design
Spacious design with enough room even for the largest components
Integrated PWM and ARGB hub
Easy and tool-free installation of HDDs and SSDs
Tinted side window made of tempered glass allows a great insight
Removable dust filters: 2x (1x front, 1x bottom)
PCI slots: 7


Form Factor / Motherboard Compatibility:


PSU form factor: ATX PS/2
Motherboard Compatibility: E-ATX / ATX / M-ATX / Mini-ITX


Dimensions, weight, material:


Color: black
Motherboard compatibility: E-ATX / ATX / M-ATX / Mini-ITX
Case dimensions excl. feet (L x W x H): 550 x 247 x 503 mm
Case dimensions incl. feet (L x W x H): 550 x 247 x 522 mm
Form factor PSU: ATX PS/2
Weight: 12.3 kg
Material: steel, plastic, glass


Maximum fan installation:


Maximum fans: 8
Top: 3x 140 / 3x 120 mm
Front: 3x 140 / 3x 120 mm
Rear: 1x 140 / 1x 120 mm
Bottom: 1x 140 / 1x 120 mm


Pre-installed fans:


Fan front: 3x Light Wings White 140 mm PWM
Fan rear: 1x Light Wings White 140 mm PWM
Dimensions (L x W x H): Front: 140 x 140 x 25 mm / Rear: 140 x 140 x 25 mm
Speed at 100% PWM / 12V: 1500 rpm
Air flow at 100%: 56 / 95.14 CFM / m3/h
Air pressure at 100% PWM / 12V: 1.49 mm H2O
Noise level at 100% PWM / 12V: 23.3 dB(A)
Voltage range: 5 - 13.2 V DC
Power consumption: 3.84 W
Rated current: 0.32 A
Connector plug: 4-pin PWM
Life expectancy @ 25 °C: ca, 60000 h


Optional radiator installation:


Top: 120 / 140 / 240 / 280 / 360 / 420 mm
Front: 120 / 140 / 240 / 280 / 360 / 420 mm
Rear: 120 mm


Power supply compatibility:


Maximum dimensions excl. fan at the case bottom: 305 mm
Maximum dimensions incl. fan at the case bottom: 260 mm


Graphics card compatibility:


With HDD cage (in height of the graphics card): 430 mm
Without HDD cage (in height of the graphics card): 430 mm
Maximum PCI slots with vertical graphics card: 7


Drive capacity:


3.5 slots (included): 2
3.5 slots (max.): 2
2.5 slots (included): 4
2.5 slots (max.): 8


Cooling:


Max. installation height of the CPU cooler: 180 mm
Air channels: Front / Top / Rear / Bottom


Lighting:


LED lighting
LEDs: 40
LED technology: ARGB - 5V
LEDs synchronizable with control / motherboard


I/O Panel:


1x USB Type-C 3.2 Gen. 2
2x USB Type-A 3.2 Gen 1
1x HD-Audio


Isolation and damping:


Side panel noise insulated
Decoupled HDD cages
Decoupled fans
Decoupled power supply
Horní strana: 1x 120 mm / 1x 140 mm / 1x 240 mm / 1x 280 mm / 1x 360 mm / 1x 420 mm
Přední strana: 1x 120 mm / 1x 140 mm / 1x 240 mm / 1x 280 mm / 1x 360 mm / 1x 420 mm
Zadní strana: 1x 120 mm
Horní strana: 3x 140 / 120 mm
Spodní strana: 1x 120 mm / 1x 140 mm
Přední strana: 3x 120 mm / 3x 140 mm
Zadní strana: 1x 120 mm / 1x 140 mm
Typ pouzdra: Počítačová skříň Midi-Tower
Mechanika 2,5 : 4x
Mechanika 3,5 : 2x
PCIe rozšiřující sloty: 7x
Osvětlení: ano
Izolace: ano
Boční díl: Okno
Síťový adaptér: volitelný
Max. výška ventilátoru CPU (mm): 180
Max. délka grafické karty (mm): 430
Nainstalované ventilátory: 4x 140 mm
ATX: ano
Micro-ATX: ano
ATX-extended (E-ATX): ano
Mini-ITX: ano
USB-A: 2x USB-A 3.2 Gen 1 (5 GBit/s)
USB-C: 1x USB-C 3.2 Gen 2 (10 GBit/s)
Připojení sluchátek: 1x
Připojení mikrofonu: 1x
Barva: černá / transparentní
Materiál: Ocel / sklo / plast
Šířka (cm): 24,7
Výška (cm): 52,2
Hloubka (cm): 55,0
Hmotnost (kg): 12,3

---
