Popis produktu

eHBA 9600-8i8e Tri-Mode Storage Adapter


x8, PCIe 4.0 eHBA features 8 internal and 8 external ports for high-performance and increased connectivity


The 9600-8i8e Tri-Mode, PCIe Gen 4.0 enhanced HBA (eHBA) is ideal for increased connectivity and maximum performance for enterprise data center flexibility.

With increased bandwidth and IOPS performance compared to previous generations, the 9600-8i8e eHBA delivers the performance and scalability needed by critical applications.


Low profile, half-length x8 PCIe Gen 4.0 adapter
Connect up to 240 SAS/SATA devices or 32 NVMe devices
Hardware Secure Boot and SPDM Attestation support
SMART monitoring
Drive temperature monitoring
SafeStore key management for attached SEDs
Universal Bay Management (UBM) Ready






Product
Manufacturer Part #
What's in the Box




eHBA 9600-8i8e
05-50145-01
9600-8i8e eHBA, Low Profile Bracket, FH (attached)











Specification
Value




Lifecycle
Active


Distributor Inventory
No


Brackets
Full height and low profile


Data Transfer Rates
22.5, 12 and 6Gb/s SAS and 6Gb/s SATA


Devices Supported
SAS/SATA: 240; NVMe: up to 32


External Connectors
2 x4 SFF-8644


External Ports
8


Generation
24G


Host Bus Adapters

x8, PCIe 4.0 eHBA features 8 internal and 8 external ports for high-performance and increased connectivity



Host Bus Type
x8 lane PCI Express 4.0


Internal Connectors
1 x8 SFF-8654 (SlimSAS)


Internal Ports
8


Management Software
LSI Storage Authority (LSA), StorCLI (Command-Line Interface), HII (UEFI Human Interface Infrastructure)


MTBF
> 5,000,000 hours at 40° C


Operating Humidity
5% to 90% Non-condensing


Operating Temperature°C
0°C to 55°C


OS Support
Microsoft Windows, VMware vSphere, VMware vSphere/ESXi, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu Linux, Citrix XenServer, CentOS Linux, Debian Linux, Oracle Enterprise Linux, Fedora, FreeBSD


Physical Dimensions
6.600" x 2.712"


Regulatory Certifications
Australia/New Zealand RCM (AS/NZS CISPR 32; CISPR 32:2015, Class A; AS/NZS CISPR 32:2015, Class A), Canada EMC (ICES-003:2016 Issue 6: 2016, Class A; CAN/CSA CISPR 22-10; CISPR 22:2008), Europe (CE) (EN 55024, EN 55032, EN 55035; EN 55032:2015 +AC:2016, Class A; EN 55024:2010 +A1:2015; EN 55035:2017 +A11:2020), Korea (KN32/KN35), Taiwan BSMI (CNS 13438; CNS15663), USA/Canada Safety (UL Listed) (UL 62368-1, Second Edition; CAN/CSA C22.2 No. 62368-1-14), USA/Canada (FCC) (47 CFR FCC Part 15, Subpart B, Class A; ANSI C63.4:2014; CISPR 32:2008) CB (IEC 62368-1:2014 (Second edition); EN 62368-1:2014+A11: 2017), Japan (V-3/2015.04, Class A; V-4/2012.04; VCCI-CISPR 32:2016; CISPR 32:2015), Morocco (CMIM) (EN 55024, EN 55032, EN 55035; EN 55032:2015 +AC:2016, Class A; EN 55024:2010 +A1:2015; EN 55035:2017 +A11:2020); RoHS, WEEE


Warranty
3 years, free technical support, advanced replacement option at broadcom.com/support/warranty/internal-raid-hba


What's in the box
9600-8i8e eHBA, Low Profile Bracket, Bracket, FH (attached)

---
