Popis produktu

SMART SERIES

80 PLUS Bronze certified efficiency
DC-to-DC technology
OCP and OTP Protection
Long Life 9cm fan


TECHNICAL SPECIFICATIONS



Model
Smart 350 W


Article no.
BFX-350BS


EAN code
0753263077486


Weight (wthout/with package)
1 kg / 1.3 kg


AC input
100 - 240 V / 5.0A


Frequency
47 - 63 Hz


+5V
18.0 A


+3.3 V
18.0 A


+5 V & +3.3 V combined
110 W


+12 V1
29.16 A


+12V2
-


+12V1, +12V2 combined
349.92 W


P.F.
>0.9


-12 V
0.3 A / 3.6 W


+ 5VBS
2.5 A / 12.5 W


Maximum Power
350 W


Connectors


20+4 PIN ATX
1


8 PIN EPS (4+4)
1


8 PIN PCIe (6+2)
1


SATA
3


MOLEX
2/1


Cable length (mm)


20+4 PIN ATX
350


8 PIN EPS (4+4)
350


8 PIN PCIe (6+2)
350


SATA
3 x 250


MOLEX / FLOPPY
2 x 150 / 150


Features


ATX12V Version
ATX 12V 2.3


Efficiency
80+ Bronze


Dimension (D x W x H)
100 x 125 x 64mm


PFC
Active PFC (0,9)


Fan
90 mm silent fan


Security
AFC (Automatic Fan speed Control) OCP (Overcurrent protection) OPP (Overload protection) OTP (Over-temperature protection) OVP (Overvoltage protection) SCP (Short-circuit protection) SIP (Surge & Inrush Protection) UVP (Under Voltage protection)


Warranty
24 Months

---
