* CAC-1567 - The Club 3D USB Type C to DisplayPort™ 1.4 Adapter 8K60Hz provided the source supports DSC1.2 HBR3 allows you to connect any USB Type C source to DisplayPort™ display at max 8K60Hz resolution and HDR support. This Adapter also works with those VR glasses which require 3.3V support. It works on any USB Type C host that supports DP 1.4/DP 1.2 Alt mode, resolutions are limited to the source device. When working on Thunderbolt™ 3 host, this product transmits DP signal. The soft UltraFlex jacket protects the cable from bends and deformation damage. The Cable is 34AWG and Uni-Directional.

Features

Supports USB Type C input and DisplayPort™ output
Supports DisplayPort™ resolutions up to 7680x4320@60Hz HDR, provided the source supports DSC1.2 and DP Alt-Mode 1.4
Supports DisplayPort™ 1.4/1.2 Alt mode
Support for 3.3V VR glasses
Compliant to Thunderbolt 3 specifications
Supports per lane data rates of 8.1Gbps(HBR3), 5.4Gbps (HBR2), 2.7Gbps (HBR) and 1.62Gbps (RBR)
Support up to 48 bit (16bit per channel) deep color
Supports content protection of HDCP1.4 & HDCP 2.2
USB bus power (no external power supply)


TECHNICAL SPECIFICATIONS



Product Series
Adapter


EAN
8719214471460


OS Support
All


Input
USB Type C male


Output
DisplayPort™ 1.4 female


Box contents
Active Adapter


Cable size
22 cm


Total weight
74 g


USB Type C Male connector
2.2 x 0.7 x 1.3 cm


DisplayPort Female connector
5.4 x 1.1 x 2.2 cm


Certifications
Meets ROHS, FCC, and CE EMI requirements

---
