Popis produktu

SPECIFICATIONS:





Application


CPU Socket
LGA 1700


CPU
Recommend for Intel® Alder Lake S Processor


Solution
Active Cooler for 3U & up workstation


Technical Data


Overall dimension
91.0 x 91.0 x 110.0 mm


Weight
530 ± 5g


Heat Sink


Material
Aluminum Fins, 4x Heat Pipes with H.C.C. Technology


Fan


Fan Dimension
92 x 25 mm


Speed
At Duty Cycle 0~20%: 1600 ± 200 RPM
At Duty Cycle 50%: 2850 ± 10% RPM
At Duty Cycle 100%: 6000 ± 10% RPM


Bearing
2 Ball Bearing


Rated Voltage
12 V


Power
At Duty Cycle 0~20%: 0.72W
At Duty Cycle 50%: 1.48W
At Duty Cycle 100%: 9.60W


Air Flow
At Duty Cycle 0~20%: 21.45 CFM
At Duty Cycle 50%: 48.83 CFM
At Duty Cycle 100%: 107.25 CFM


Noise Level
At Duty Cycle 0~20%: 16 dBA
At Duty Cycle 50%: 32.20 dBA
At Duty Cycle 100%: 50.40 dBA


Static Pressure
At Duty Cycle 0~20%: 0.68 mm-H2O
At Duty Cycle 50%: 5.34 mm-H2O
At Duty Cycle 100%: 17.10 mm-H2O


Lead Wire Pin Out
Pin1-Black (-)
Pin2-Yellow (+)
Pin3-Green (Tachometer/Signal output)
Pin4-Blue (PWM)


Thermal grease
Pre-printed

---
