Technical Specifications




80PLUS
Titanium


Cybenetics Efficiency Level
TBA


Cybenetics Noise Level
TBA


Form Factor
Intel ATX 12 V


Dimensions
170 mm (W) x 150 mm (L) x 86 mm (H)


Fan Information
Fan Size
135 mm


Fan Control
Premium Hybrid Fan Control


Fan Bearing
Fluid Dynamic Bearing


Life Expectancy
50,000 hours at 40 °C, 15 % - 65 % RH


Cable Information
Modularity
Fully Modular


Cable type
Flat black cables


Electrical Features
Operating Temperature
0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)


MTBF @ 25 °C, excl. fan
150,000 hours


AC Input
Full Range


Protection
OPP, OVP, UVP, OCP, OTP, SCP


Safety and Environmental
Safety and EMC
cTUVus, TUV, CB, CCC, BSMI, EAC, CE


Environmental Compliance
Energy Star, RoHS, WEEE, ErP Lot 6, REACH


Warranty
12 Years






Power Output




AC Input
Voltage: 100 V - 240 V


Current: 9.5 - 4.5 A


Frequency: 50 Hz - 60 Hz


DC Output
Rail
+3.3 V
+5 V
+12 V
-12 V
+5 VSB


Maximum Power
20 A
20 A
62 A
0.3 A
3 A


100 W
744 W
3.6 W
15 W


Total continuous power
750 W



SSR-750TR



Connector
Connector count
Cable count
Cable


Main Power (24/20 pins)
1
1



CPU (8/4 pins)
2
2



PCIe (8/6 pins)
4
4



0



SATA
10
0



1



1



0



1



Peripheral
5
1



1



Floppy
1
1

---
