Shelly Pro Dimmer 0/1-10V PM lighting controller
The Shelly Pro Dimmer Lighting Controller supports both 0-10V and 1-10V controllers, so you can smoothly adjust the brightness of your lights to create the perfect ambience - from moody evening lighting to bright light conducive to work. The device offers full control over energy consumption, helping you lower your electricity bill and minimize your carbon footprint. You can easily integrate it into your existing lighting installations and use it with your favorite switches. Using it does not require a hub.
Integration with switches
Shelly Pro Dimmer works with single- and double-key switches, offering full flexibility to adapt to your preferences. With the ability to connect the Shelly Plus Add-On, the controller extends its functions to monitor environmental parameters such as humidity, temperature and light intensity. With this solution in place, you can fine-tune the conditions in your home to suit your needs, regardless of the style of switches you use.
Energy monitoring
The Shelly Pro Dimmer 0/1-10V PM precisely tracks voltage, current and power in real time. The collected data is available in the Shelly Smart Control app. The controller not only monitors energy consumption, but also helps optimize its use, leading to reduced bills. Current, voltage and power overload protections increase the safety of your electrical system.
Smart schedules and night mode
With Shelly Pro Dimmer, you can easily program lighting schedules that adapt to your lifestyle. Night mode automatically lowers the brightness level to create a cozy atmosphere, perfect for evening relaxation. Whether you re planning a movie night or want to gently dim the lights before bed, the controller will adapt to your needs.
Support for multiple protocols and platforms
Don t worry about potential compatibility issues. The Shelly Pro Dimmer lighting controller supports advanced communication protocols such as KNXnet/IP, MQTT and REST/Webhooks, allowing full integration with smart home platforms. It works with Home Assistant, Google Home, Amazon Alexa and more, offering easy lighting management with simple voice commands. The Wi-Fi Range Extender and Bluetooth Gateway feature allows for even greater range and connectivity flexibility.
Future-proof solution
The use of Shelly s advanced ESP32 C3 processor and 8 MB of flash memory makes the Shelly Pro Dimmer controller ready for future upgrades and new features, such as integration with the Matter standard. Thanks to this technology, the device runs smoothly and quickly, ensuring long-term stability and support for the latest smart home innovations.

Manufacturer
Shelly
Manufacturer code
ProDim0/1-10VPM
Dimensions
38.5 x 43.5 x 17 mm
Weight
28.5 g
Maximum tightening torque
0.4 Nm
Cable cross section
0.2 to 2.5 mm2
Wire stripping length
5-6 mm
Housing material
Plastic
Mounting location
In wall console/behind wall/ceiling structure
Operating temperature
From -20°C to 40°C
Humidity
30% to 70% RH
Maximum operating altitude
2000 m
Power supply
110-240 V~ 50/60 Hz
Power consumption
External protection
16A, trip characteristic B or C, short-circuit current 6 kA, energy limit class 3
Maximum switching voltage
240 V~
Maximum switching current
13 A
Maximum control current
35 mA
Voltmeter voltage range
110 - 240 V
Ampere range
50 mA - 16 A
Accuracy of the meters
±10%
Power and energy meters
Active and apparent power / Active and apparent energy
Measurement data storage
None
Built-in temperature sensor
Yes
Wi-Fi protocol
802.11 b/g/n
RF bandwidth
2401-2495 MHz
Maximum RF power
Wi-Fi range
Up to 30 m indoors and up to 50 m outdoors (depending on local conditions)
Bluetooth protocol
4.2
RF band
2400-2483.5 MHz
Maximum RF power
Bluetooth range
Up to 30 m outdoors, up to 10 m indoors (depending on local conditions)
CPU
Shelly ESP32 C3
Clock frequency
40 MHz
Flash memory
8 MB
Number of schedules
20
Webhooks (URL shares)
20 with 5 URLs per webhook
Scripts
Yes
MQTT
Yes
Advanced scheduling
Yes
KVS (Key-Value Store)
Yes
Compatibility and Communication
Protocols: KNXnet/IP, MQTT, REST/Webhooks, URC, Homey, Hubitat, Control4, Crestron, openHAB / Platforms: Alexa, Google Home, Android, iOS / App Compatibility: Home Assistant, Smart Things, Homey

---
