Popis produktu

Key Features

1. 12G Rear 2.5"x2 Drive Kit

2. Hot-swappable SAS3/SATA3 Drives

3. Drive Activity and Status(Fail) LED Support

4. Tool-less HDD Trays

5. SGPIO, Power extension Y-cable and 6G data cables are included

6. Optional 12G cable CBL-SAST-0699 (internal mini SAS HD to 4 SAS/SATA) available



Specifications











Specifications





Dimensions


3.26"W x 1.36"H x 6.26"D (83mm x 35 x 159mm)




Gross Weight


1.5 lbs (0.68 Kgs)




Available Colors


Black (CSE-MCP-220-82616-0N)




Occupancy


2x 2.5" Drive Bays




Capacity


2x 2.5" Hot-swap SAS/SATA Hard Drives




Cooling Subsystem


N/A (via chassis fan)




System Monitoring


Overheat LED and Alarm
Drive Activity LED and Failure LED





















Compatibility





Chassis
? SC226S, SC826S, SC216B Series

? SC846X, SC847B, SC417B Series














Parts List









Standard Parts List






Part Number
Qty
Description


HDD Backplane
BPN-SAS3-826TQ-B2B
1
2-Port 12Gbps Backplane for 2x2.5" SAS/SATA HDD/SSD


HDD Tray
MCP-220-00117-0B
2
Black gen-3 hot-swap tool-less 2.5" HDD tray


Cable
CBL-CDAT-0841
1
8 pin to 8 pin round SGPIO cable, 81cm, 28AWG, pinout 1-1


Cable
CBL-0481L(81cm)
2
81CM 30AWG SATA S-S cable


Cable
CBL-0234L
1
4-PIN POWER SUPPLY Y-CABLE FOR HDD, 15CM, 20AWG












Optional Parts List






Part Number
Qty
Description


Cable
CBL-SAST-0699(75cm)
--
Internal 12G mini SAS HD to 4 SAS/SATA, 75/75/90/90cm w/75cm SB, S. 30AWG,RoHS/REACH

---
